VAR-MX6CustomBoard

The VAR-MX6CustomBoard Single Board Computer ( SBC ) can serve both as a development platform and as an end product. In conjunction with the VAR-SOM-MX6, it offers an even wider connectivity with additional interfaces such as RS485, Gigabit Ethernet, LVDS, etc.

    Specifications

    SODIMM 200 socket

    Supporting the VAR-SOM-MX6 (not included)

    Display

    RGB

    18-bit RGB parallel display interface (40-pin FFC/FPC connector for 7″ WVGA LCD)

    LVDS

    18-bit / 24-bit

    HDMI

    1.4

    Backlight Driver

    Yes

    Audio

    Headphone

    3.5 mm connector

    Line – in

    3.5 mm connector

    Digital microphone

    on-board

    Touch Panel

    Resistive

    4-wire touch panel, 4-pin FFC/FPC

    Capacitive

    Capacitive touch panel, (10-pin FFC/FPC)

    Camera interfaces

    Serial Camera

    Interfaces with the VAR-EXT-CB402 Camera Board

    Parallel Camera

    Header

    USB

    USB Host

    3 ports, Type A connector

    USB OTG

    Type Mini AB connector

    Expansions

    SD-CARD

    SD Card Socket

    S-ATA

    7 + 15, female connector

    PCI-Express

    mini-PCIe connector

    SIM Card

    Supporting mini-PCIe modem

    Serial Ports

    RS232 (1)

    DV-9 male (DTE)

    RS232 (2)

    IDC10 Header (Debug)

    RS485

    Header

    CAN Bus

    CAN bus interface with isolator and driver

    Expansion Connectors

    EIM – Local Bus interface

    SD/MMC interface

    SPI, I2C

    UART

    GPIOs

    JTAG

    Ethernet

    10/100/1000 Mbps, RJ45

    Mechanical Specifications

    Dimensions (W x L x H)

    12 cm x 10.5 cm x 2.4 cm

    Electronic Specifications

    Supply voltage

    7.5V -14V DC input, 2.5 mm DC jack

    RTC

    Coin RTC Backup battery socket (CR1225)

    VAR-SOM-MX6 Evaluation Kits Block Diagram Diagram
