VAR-SOM-SOLO/DUAL
NXP/Freescale iMX6
Staying on-trend with the market’s shift towards a cost-effective highly integrated off-the-shelf solution, the VAR-SOM-SOLO and VAR-SOM-DUAL from Variscite level the playing ground for a broad spectrum of embedded products. Bringing all the benefits of the widely successful VAR-SOM-MX6, the VAR-SOM-SOLO/DUAL from Variscite carries much smaller dimensions and a slim-lined price-point. Features include NXP/Freescale’s iMX6 Solo/Dual Lite core, 1GHz Cortex-A9, SLC NAND, eMMC, dual-band certified Wi-Fi/BT with MIMO, USB, Gigabit Ethernet, A/V interfaces and industrial operating temperatures.
The Dual and Quad core i.MX6 are supported by the VAR-SOM-MX6-V2 System on Module/ Computer on Module.
For the complete Pin2Pin product list, check the Variscite Pin2Pin System on Module families.
** The Pin2Pin compatibility depends on pinmux options; please verify the detailed pinout table in the related SoM to confirm compatibility is maintained in your specific design.
Highlights
CPU
1GHz Single/Dual Cortex™-A9 NXP iMX6
Graphics Acceleration
Vivante GC 880 + Vivante GC 320
Certified WiFi/BT
802.11 a/b/g/n + BT 5.1/BLE
Temperature range
-40 to 85°C
Multimedia
Vivante GC 880 + Vivante GC 320
Product Longevity
2035
Support
Supporting you every step of the way - from ideation to launch and beyond.
Free and prompt support directly from Variscite’s R&D experts.
Quick Links
Specifications
CPU Name
NXP/Freescale i.MX6
CPU Type
Cortex™-A9 MPCore™
CPU Cores
1-2 Cores (2-4 cores supported by the VAR-SOM-MX6_V2 SoM)
CPU Clock (Max)
1 GHz
Integer performance (DMIPS)
Up to 5,000
RAM
256 - 1024 MB DDR3
SLC NAND
128 - 512 MB SLC NAND
eMMC
8 - 128 GB
Multimedia
2D/3D Graphics Acceleration
Vivante GC 880 + Vivante GC 320
Video Encode / Decode
1080p30 H.264 Decode, 1080p30 H.264 Encode
Camera Interfaces
1x CSI, 1x CPI
Display
HDMI
v1.4 1920 x 1080
LVDS
Dual 1366 x 768 24-bit
DSI
1280 x 720 24-bit
Touch controller
Resistive, Capacitive
Audio
Headphone driver
Yes
Microphone
Digital
Digital audio serial interface
S/PDIF
Line In/Out
Yes
Connectivity
SD / MMC
x1
USB Host / Device
USB 2.0 : 1x Host, 1x OTG
UART
x5, up to 5 Mbps
I2C
x3
SPI
x3
RTC
On carrier
PCI-Express
Gen 2.0
CAN Bus
x2
Networking
Ethernet
10/100/1000 Mbps
Wi-Fi
Certified 802.11 a/b/g/n + MIMO
Bluetooth
5.1 + CSA2 support / BLE
Linux
Yocto, Debian, Boot2Qt
Android
Yes
Mechanical Specifications
Dimensions (W x L)
67.8 x 33.0 mm
Electronic Specifications
Supply voltage
3.3 V
Digital I/O voltage
3.3 V
Environmental Specifications
Commercial operating temperature
0 to 70°C
Extended operating temperature
-20 to 70°C
Industrial operating temperature
-40 to 85°C
Storage temperature
-40 to 85°C
Storage humidity
5% to 95%
VAR-SOM-[SOLO / DUAL]_[xxxx]C_[xxxx]R_[xxx]N_[x]G_[AC]_[EC]_[TP]_[WB[D]]_[x]T_LO
[SOLO / DUAL]
CPU type: SOLO : i.MX6 SOLO, DUAL : i.MX6 Dual Lite
[xxxx]C:
Clock speed: 1000MHz : 1000C, 800MHz : 800C(Industrial)
[xxx]R:
RAM size: 256MB : 256R, 512MB : 512R, 1024MB : 1024R
[xxx]N:
NAND size: 128MB : 128N, 256MB : 256N, 512MB : 512N
[x]G:
eMMC size: 0GB: 0G, 8GB : 8G, 16GB : 16G, 32 GB : 32G, 64 GB : 64G
[EC]:
10/100/1000Mbps Ethernet PHY
[AC]:
Audio Codec
[TP]:
4-wire Touch Panel.
Note: Capacitive touch is natively supported through I2C in the base configuration
Note: Capacitive touch is natively supported through I2C in the base configuration
[WB[D]]
WB: Built-in certified Wi-Fi 802.11 b/g/n + Bluetooth 5.1 + CSA2 support/BLE (CT/ET only)
WBD: Built-in certified Wi-Fi 802.11 a/b/g/n with MIMO + Bluetooth 5.1 + CSA2 support/BLE
WBD: Built-in certified Wi-Fi 802.11 a/b/g/n with MIMO + Bluetooth 5.1 + CSA2 support/BLE
[x]T:
C : 0 to 70°C, E : -20 to 70°C, I : -40 to 85°C
