VAR-DT8MCustomBoard
The VAR-DT8MCustomBoard Single Board Computer (SBC) can serve both as a development platform and as an end product. In conjunction with the DART-MX95, DART-MX93, DART-MX8M, DART-MX8M-MINI, DART-MX8M-PLUS, it offers even wider connectivity with additional interfaces such as Gigabit Ethernet PHY, camera interfaces, LVDS, PCIe, RTC etc.
Specifications
SOM Interface
B2B socket
Compatible products
Display
LVDS
18-bit / 24-bit
HDMI
2.0a (DART-MX8M and DART-MX8M-PLUS only)
DP
1.3 (DART-MX8M only)
Backlight Driver
PWM Control
Audio
Headphone
3.5 mm connector
Line - in
3.5 mm connector
Digital microphone
on-board
Touch Panel
Resistive
4-wire touch panel (4-pin FFC/FPC)
Capacitive
Capacitive touch panel (6-pin FFC/FPC)
Camera Interface
Serial Camera
Interfaces with the VCAM-5640S Camera Board
USB
USB Host
DART-MX8M: 2 ports, Type A connector, USB3.0/2.0.DART-MX8M-MINI: 2 ports, Type A connector, USB2.0.
USB OTG
DART-MX8M: Type C connector, USB3.0/2.0.DART-MX8M-MINI: Type C connector, USB2.0.DART-MX8M-PLUS: 2x USB3.0.
Expansions
PCI-Express
DART-MX8M: mini-PCIe connector x2DART-MX8M-MINI: mini-PCIe connector x1
SD-CARD
SD Card Socket
Serial Ports
RS232 (1)
USB-SERIAL bridge, Micro USB type AB
RS232 (2)
FTDI Header (Debug)
RS232 (3), (4)
Header
Expansion Connectors
QSPI
Yes
UART
Yes
SPI, I2C
Yes
GPIOs
Yes
JTAG
Yes
SAI
Yes
SPDIF
Yes
Ethernet
10/100/1000 Mbps, RJ45DART-MX8M-PLUS: 2x 10/100/1000 Mbps
Mechanical Specifications
Dimensions (W x L x H)
15 cm x 9 cm x 1.5 cm
Electronic Specifications
Supply voltage
5V DC input, 2.5 mm DC jack
RTC
Coin RTC Backup battery socket (CR1225)
